Rubber Plastic Composite Hose Line
Taking advantage of our strength of being able to manufacture both rubber extruders and plastic extruders, we have various line-ups such as a line with a mandrel like this equipment and a line that extrudes rubber and plastic at the same time.
Our fluororesin extruder uses an extruder's material with excellent corrosion resistance.
Abundant Product Composition met applications and needs you have!! The rubber extruder, which is one of our signboard products of Mitsuba Manufacturing Co., Ltd. has been adopted by many users both in Japan and overseas, with nearly 100 extruders annually since its establishment.
addition to its achievements and experience, we design screws and flow paths in-house based on material data that makes full use of measuring instruments such as Brabender viscometers and Capillary rheometers, and we also assemble in-house major parts with our own high-performance processing machines and skilled technicians.
Having small extruders like screw size φ20 mm to larger large extruders like φ200 mm, our extruders are used in various fields such as automobile hoses and tyres, building sealing parts, medical tubes, electric cables, and printing rolls and so forth. If advising us the application and specifications, we are glad to propose the most suitable equipment including front and rear equipment.
Straighthead / Crosshead
Mainly use straighthead in case of single layer tube or sheet extrusion, use crosshead for coating or multi layer extrusion.
Multi Layer Head
It is effective for rubber material products including complicate shaped sponge-solid and frequent uneven thickness products.
In addition to conventional extruded products using general-purpose resins such as PVC and polyethylene, the plastic extruder is used in development products in various fields such as cables, tubes and films that take advantage of its strength and other features of heat resistance and chemical resistance of high-performance resin materials called super engineering plastics such as polyamide, polyurethane and other engineering plastics like fluoro-resins, PEEK materials and PPS materials, etc.
Plastic extruder made by Mitsuba mfg,. using various plastics and designed and manufacturing in-house from low discharge extruder screw sized 14 mm to high discharge extruder screw sized 150 mm include screws and molds try to achieve require specification for each industry and providing high quality extruders.
It is available each size from the minimum screw size φ14 mm to φ50 mm.。
※Please contact us separately for screw diameter more than φ50 mm. There is constraint such as materials.
Corrosion-resistant metal is naturally used where the resin comes into direct contact, such as the cylinder, screw, and head.
